OP802SL
SENSOR PHOTO 890NM TOP TO206AAManufacturer: TT Electronics/Optek Technology
Categories: Phototransistors
Quality Control: Learn More
TT Electronics/Optek Technology OP802SL is a top-view phototransistor designed for applications requiring detection of infrared light at 890nm. This component features a TO-206AA (TO-18-3) metal can package, facilitating through-hole mounting. The OP802SL offers a maximum collector current (Ic) of 50 mA and a low dark current (Id) of 100 nA, ensuring reliable performance in various ambient conditions. With a maximum collector emitter breakdown voltage of 30 V and a maximum power dissipation of 250 mW, this phototransistor is suitable for demanding environments. Its operational temperature range spans from -65°C to 125°C. This device is commonly utilized in industrial automation, medical equipment, and optical sensing systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-206AA, TO-18-3 Metal Can |
| Wavelength | 890nm |
| Mounting Type | Through Hole |
| Orientation | Top View |
| Operating Temperature | -65°C ~ 125°C |
| Viewing Angle | - |
| Current - Dark (Id) (Max) | 100 nA |
| Current - Collector (Ic) (Max) | 50 mA |
| Voltage - Collector Emitter Breakdown (Max) | 30 V |
| Power - Max | 250 mW |
