OP525
SENSOR PHOTO 935NM TOP VIEW 1210Manufacturer: TT Electronics/Optek Technology
Categories: Phototransistors
Quality Control: Learn More
TT Electronics/Optek Technology OP525 is a surface-mount phototransistor designed for top-view optical sensing applications. This component features a peak sensitivity at 935nm, making it suitable for infrared detection systems. It operates with a maximum collector current of 20 mA and a collector-emitter breakdown voltage of 30 V, with a typical dark current of 100 nA. The device is housed in a 1210 (3225 Metric) package and offers a viewing angle of 25°. With a maximum power dissipation of 75 mW and an operating temperature range of -40°C to 80°C, the OP525 is a robust solution for various industrial and consumer electronics, including automation, security, and optical communication systems. The component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1210 (3225 Metric) |
| Wavelength | 935nm |
| Mounting Type | Surface Mount |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 80°C |
| Viewing Angle | 25° |
| Current - Dark (Id) (Max) | 100 nA |
| Current - Collector (Ic) (Max) | 20 mA |
| Voltage - Collector Emitter Breakdown (Max) | 30 V |
| Power - Max | 75 mW |
