OPR2100HS
SENSOR PHOTODIODE 890NM ARRAYManufacturer: TT Electronics/Optek Technology
Categories: Photodiodes
Quality Control: Learn More
The TT Electronics/Optek Technology OPR2100HS is a surface mount photodiode array designed for applications requiring high sensitivity at 890nm. This component features six individual photodiodes, each with an active area of 3.45mm², providing a total active area for enhanced light detection. The OPR2100HS exhibits a responsivity of 0.45 A/W at its peak wavelength of 890nm and operates across a spectral range of 400nm to 1100nm. It is a pin photodiode type with a dark current of 10nA (typical) and a maximum reverse voltage of 50V. The device is rated for operation within an extended temperature range of -55°C to 125°C and is supplied in tube packaging. This photodiode array is suitable for use in various industries, including industrial automation, medical devices, and optical sensing systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | - |
| Wavelength | 890nm |
| Mounting Type | Surface Mount |
| Diode Type | Pin |
| Operating Temperature | -55°C ~ 125°C |
| Response Time | - |
| Viewing Angle | - |
| Spectral Range | 400nm ~ 1100nm |
| Color - Enhanced | - |
| Responsivity @ nm | 0.45 A/W @ 890nm |
| Active Area | 3.45mm² (x6) |
| Current - Dark (Typ) | 10nA |
| Voltage - DC Reverse (Vr) (Max) | 50 V |
