OVM4RTX
LED RED CLEAR TO46 T/HManufacturer: TT Electronics/Optek Technology
Categories: LED Indication - Discrete
Quality Control: Learn More
TT Electronics/Optek Technology OVM4RTX is a red, diffused LED designed for discrete indication applications. This through-hole component features a 624nm dominant wavelength with a peak wavelength of 630nm, emitting a luminous intensity of 3300mcd at a forward current of 20mA. The device operates at a typical forward voltage of 1.8V and is housed in a TO-46-2 metal can package with a clear, domed top lens. Its compact size and specialized optical characteristics make it suitable for use in industrial automation, medical instrumentation, and consumer electronics where reliable visual feedback is critical. The TO-46 package with a 18° viewing angle ensures focused illumination.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | TO-46-2 Lens Top Metal Can |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 3300mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.8V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 18° |
| Height (Max) | 4.79mm |
| Wavelength - Peak | 630nm |
| Wavelength - Dominant | 624nm |
| Supplier Device Package | TO-46 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 4.63mm Dia |
