OVFSG7C8
LED GREEN CLEAR T/HManufacturer: TT Electronics/Optek Technology
Categories: LED Indication - Discrete
Quality Control: Learn More
TT Electronics/Optek Technology's OVFSG7C8 is a through-hole mounted green LED designed for indication applications. This discrete component features a 527nm dominant wavelength and a clear, round, domed lens with a 3.00mm diameter, providing a 70° viewing angle. It operates with a typical forward voltage of 3.6V and a test current of 30mA. Packaged in a 4-DIP (0.200", 5.08mm) format, the OVFSG7C8 is suitable for various industrial and commercial electronic systems requiring reliable visual feedback. The component measures 7.60mm L x 7.60mm W with a maximum height of 5.94mm.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 4-DIP (0.200"", 5.08mm) |
| Color | Green |
| Size / Dimension | 7.60mm L x 7.60mm W |
| Mounting Type | Through Hole |
| Millicandela Rating | - |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.6V |
| Lens Color | Colorless |
| Current - Test | 30mA |
| Viewing Angle | 70° |
| Height (Max) | 5.94mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 527nm |
| Supplier Device Package | - |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 3.00mm Dia |
