OVS5MBBCR4
LED BLUE 465NM SMDManufacturer: TT Electronics/Optek Technology
Categories: LED Color Lighting
Quality Control: Learn More
TT Electronics/Optek Technology OVS5MBBCR4 is a high-intensity blue LED designed for demanding illumination applications. This surface-mount component, housed in a 1414 (3535 Metric) package, emits light at a peak wavelength of 465nm, with a typical forward voltage of 3.4V and a maximum forward current of 180mA. Tested at 150mA, it achieves a luminous flux of 7 lumens and an efficacy of 14 lumens per watt, with a wide 120-degree viewing angle. Its compact 3.50mm x 3.50mm footprint and 1.40mm seated height make it suitable for space-conscious designs. The OVS5MBBCR4 is supplied on tape and reel for automated assembly and finds application in automotive lighting, industrial indicators, and general backlighting solutions.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1414 (3535 Metric) |
| Color | Blue |
| Wavelength | 465nm (460nm ~ 470nm) |
| Size / Dimension | 0.138"" L x 0.138"" W (3.50mm x 3.50mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.4V |
| Current - Test | 150mA |
| Viewing Angle | 120° |
| Current - Max | 180mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 14 lm/W |
| Height - Seated (Max) | 0.055"" (1.40mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 7lm (5lm ~ 8lm) |
