OPA741G23
LED MOD OPA741 GREEN RINGManufacturer: TT Electronics/Optek Technology
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
TT Electronics/Optek Technology OPA741G23 is a green LED module from the OPA741 series, featuring a disc-shaped configuration. This component offers a typical luminous flux of 490lm at a forward voltage of 21.6V and a test current of 700mA, achieving 32 lm/W. The module has a viewing angle of 23° and a wavelength of 530nm. Its dimensions are a 158.80mm diameter with a height of 1.68mm and a flat lens type. This LED module is utilized in applications requiring focused, high-intensity green illumination, commonly found in industrial lighting, signage, and specialty optical systems.
Additional Information
Series: OPA741RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: -Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | - |
| Color | Green |
| Wavelength | 530nm |
| Size / Dimension | 158.80mm Dia |
| Type | LED Module |
| Configuration | Ring (Disc) |
| Voltage - Forward (Vf) (Typ) | 21.6V |
| Height | 1.68mm |
| Current - Test | 700mA |
| Viewing Angle | 23° |
| Lens Type | Flat |
| Current - Max | - |
| Lumens/Watt @ Current - Test | 32 lm/W |
| CCT (K) | - |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 490lm (Typ) |
