OPA731Y
LED MOD OPA731 YELLOW RECTManufacturer: TT Electronics/Optek Technology
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
TT Electronics/Optek Technology OPA731Y is a Yellow Rectangle LED Module from the OPA731 series, designed for high-performance lighting applications. This electronic component delivers a typical luminous flux of 700lm at 1.4A test current, achieving 40 lm/W efficiency at 25°C. The module operates with a forward voltage of 12.5V and features a wide 120° viewing angle. Its emission wavelength is centered at 587nm. The OPA731Y is suitable for use in general illumination, architectural lighting, and signage, providing a consistent and bright yellow light output. The module's dimensions are 63.5mm in length and 69.84mm in width, with a height of 7.63mm.
Additional Information
Series: OPA731RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: -Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | - |
| Color | Yellow |
| Wavelength | 587nm |
| Size / Dimension | 63.5mm L x 69.84mm W |
| Type | LED Module |
| Configuration | Rectangle |
| Voltage - Forward (Vf) (Typ) | 12.5V |
| Height | 7.63mm |
| Current - Test | 1.4A |
| Viewing Angle | 120° |
| Lens Type | Flat |
| Current - Max | - |
| Lumens/Watt @ Current - Test | 40 lm/W |
| CCT (K) | - |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 700lm (Typ) |
