EN12-HN11AF20
ROTARY ENCODER MECHANICAL 12PPRManufacturer: TT Electronics/BI
Categories: Encoders
Quality Control: Learn More
TT Electronics/BI EN12 series rotary encoder, part number EN12-HN11AF20. This mechanical encoder features 12 pulses per revolution (PPR) with quadrature (incremental) output. It is designed for PCB mounting via through-hole termination and offers a vertical orientation. The unit includes a detent mechanism and a 6mm diameter flatted end actuator. With a rotational life of a minimum of 30,000 cycles, this encoder is suitable for applications in industrial automation, consumer electronics, and automotive systems where precise rotational position sensing is required.
Additional Information
Series: EN12RoHS Status: Request inventory verificationManufacturer Lead Time: 34 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Output Type | Quadrature (Incremental) |
| Mounting Type | PCB, Through Hole |
| Orientation | Vertical |
| Termination Style | PC Pin |
| Voltage - Supply | - |
| Encoder Type | Mechanical |
| Detent | Yes |
| Pulses per Revolution | 12 |
| Actuator Type | 6mm Dia Flatted End |
| Built in Switch | No |
| Rotational Life (Cycles Min) | 30k |
| Programmable | Not Verified |
