TCS20DPR,LF
MAGNETIC SWITCH OMNIPOLAR SOT23FManufacturer: Toshiba Semiconductor and Storage
Categories: Switches (Solid State)
Quality Control: Learn More
Toshiba Semiconductor and Storage TCS20DPR-LF is a digital omnipolar Hall effect switch in a SOT-23F package. This component offers a push-pull output and operates across a supply voltage range of 2.3V to 5.5V. With a typical supply current of 1.6mA and a maximum output current of 5mA, the TCS20DPR-LF features a sensing range of ±4.4mT for tripping and ±0.9mT for release. It is characterized by its ability to detect both north and south magnetic poles. This device is suitable for surface mounting and is supplied on tape and reel (TR). The operating temperature range is -40°C to 85°C. Applications for this type of component include position sensing in consumer electronics, automotive systems, and industrial automation.
Additional Information
Series: TCSRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-3 Flat Leads |
| Output Type | Push-Pull |
| Polarization | North Pole, South Pole |
| Mounting Type | Surface Mount |
| Function | Omnipolar Switch |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.3V ~ 5.5V |
| Technology | Hall Effect |
| Sensing Range | ±4.4mT Trip, ±0.9mT Release |
| Current - Output (Max) | 5mA |
| Current - Supply (Max) | 1.6mA (Typ) |
| Supplier Device Package | SOT-23F |
| Test Condition | 25°C |
