TPHR7404PU,L1Q(M
40V UMOS9 S 0.65MOHM SOP-ADV(N)Manufacturer: Toshiba Semiconductor and Storage
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 40 V 150A (Tc) 3W (Ta), 210W (Tc) Surface Mount 8-SOP Advance (5x5)
Additional Information
Series: U-MOSIX-HRoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 8-PowerVDFN |
| Mounting Type | Surface Mount |
| Operating Temperature | 175°C |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 150A (Tc) |
| Rds On (Max) @ Id, Vgs | 0.74mOhm @ 50A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 3W (Ta), 210W (Tc) |
| Vgs(th) (Max) @ Id | 3V @ 1mA |
| Supplier Device Package | 8-SOP Advance (5x5) |
| Grade | - |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 40 V |
| Gate Charge (Qg) (Max) @ Vgs | 98 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 9000 pF @ 20 V |
| Qualification | - |
Request a Quote
