TK090A65Z,S4X
MOSFET N-CH 650V 30A TO220SISManufacturer: Toshiba Semiconductor and Storage
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 650 V 30A (Ta) 45W (Tc) Through Hole TO-220SIS
Additional Information
Series: DTMOSVIRoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 Full Pack |
| Mounting Type | Through Hole |
| Operating Temperature | 150°C |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 30A (Ta) |
| Rds On (Max) @ Id, Vgs | 90mOhm @ 15A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 45W (Tc) |
| Vgs(th) (Max) @ Id | 4V @ 1.27mA |
| Supplier Device Package | TO-220SIS |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±30V |
| Drain to Source Voltage (Vdss) | 650 V |
| Gate Charge (Qg) (Max) @ Vgs | 47 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2780 pF @ 300 V |
