SSM3K36FS,LF
MOSFET N-CH 20V 500MA SSMManufacturer: Toshiba Semiconductor and Storage
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 20 V 500mA (Ta) 150mW (Ta) Surface Mount SSM
Additional Information
Series: U-MOSIIIRoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-75, SOT-416 |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 500mA (Ta) |
| Rds On (Max) @ Id, Vgs | 630mOhm @ 200mA, 5V |
| FET Feature | - |
| Power Dissipation (Max) | 150mW (Ta) |
| Vgs(th) (Max) @ Id | 1V @ 1mA |
| Supplier Device Package | SSM |
| Drive Voltage (Max Rds On, Min Rds On) | 1.5V, 5V |
| Vgs (Max) | ±10V |
| Drain to Source Voltage (Vdss) | 20 V |
| Gate Charge (Qg) (Max) @ Vgs | 1.23 nC @ 4 V |
| Input Capacitance (Ciss) (Max) @ Vds | 46 pF @ 10 V |
