2SC5233BTE85LF
TRANS NPN 12V 0.5A USMManufacturer: Toshiba Semiconductor and Storage
Categories: Single Bipolar Transistors
Quality Control: Learn More
Bipolar (BJT) Transistor NPN 12 V 500 mA 130MHz 100 mW Surface Mount USM
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Mounting Type | Surface Mount |
| Transistor Type | NPN |
| Operating Temperature | 125°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 10mA, 200mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 500 @ 10mA, 2V |
| Frequency - Transition | 130MHz |
| Supplier Device Package | USM |
| Current - Collector (Ic) (Max) | 500 mA |
| Voltage - Collector Emitter Breakdown (Max) | 12 V |
| Power - Max | 100 mW |
