JDP4P02AT(TE85L)
RF DIODE PIN 30V CST4Manufacturer: Toshiba Semiconductor and Storage
Categories: RF Diodes
Quality Control: Learn More
Toshiba Semiconductor and Storage JDP4P02AT-TE85L RF Diode is a PIN diode designed for high-frequency applications. This component features two independent PIN diode elements within a compact CST4 package (1.2x0.8mm). It offers a maximum reverse voltage of 30V and a continuous forward current of 50mA. The diode exhibits a low capacitance of 0.4pF at 1V and 1MHz, and a low forward resistance of 1.5 Ohms at 10mA and 100MHz. Operating at junction temperatures up to 150°C, this device is supplied in Tape & Reel packaging. Its performance characteristics make it suitable for use in RF switching and attenuation circuits across various telecommunications and industrial applications.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-SMD, No Lead |
| Diode Type | PIN - 2 Independent |
| Operating Temperature | 150°C (TJ) |
| Capacitance @ Vr, F | 0.4pF @ 1V, 1MHz |
| Resistance @ If, F | 1.5Ohm @ 10mA, 100MHz |
| Voltage - Peak Reverse (Max) | 30V |
| Supplier Device Package | CST4 (1.2x0.8) |
| Current - Max | 50 mA |
