TB6560AFG,8
IC MOTOR DRIVER PAR 64HQFPManufacturer: Toshiba Semiconductor and Storage
Categories: Motor Drivers, Controllers
Quality Control: Learn More
Toshiba Semiconductor and Storage TB6560AFG-8 is a bipolar stepper motor driver IC featuring a parallel interface. This fully integrated component incorporates control and power stages, delivering up to 1.5A output current per phase. The device operates within a load voltage range of 4.5V to 34V and a supply voltage range of 4.5V to 5.5V. Its output configuration comprises four half-bridge drivers. The TB6560AFG-8 is housed in a 64-HQFP (10x10) package and is designed for surface mounting. Typical applications include general-purpose motor control in industrial automation and robotics. The operating temperature range for this component is -30°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 28 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 64-TQFP Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1.5A |
| Interface | Parallel |
| Operating Temperature | -30°C ~ 85°C |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 4.5V ~ 5.5V |
| Applications | General Purpose |
| Voltage - Load | 4.5V ~ 34V |
| Supplier Device Package | 64-HQFP (10x10) |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | - |
