TMPM380FWFG
IC MCU 32BIT 128KB FLASH 100LQFPManufacturer: Toshiba Semiconductor and Storage
Categories: Microcontrollers
Quality Control: Learn More
Toshiba Semiconductor and Storage TX03 Series microcontroller, part number TMPM380FWFG. This 32-bit ARM Cortex-M3 core microcontroller operates at 40MHz, featuring 128KB of FLASH program memory and 12KB of RAM. Connectivity options include I2C, SIO, and UART/USART interfaces. It is equipped with an 18-channel 12-bit Analog-to-Digital converter and peripherals such as DMA, LVD, and WDT. The device is housed in a 100-LQFP (14x14) package for surface mounting and operates within a voltage range of 4V to 5.5V. The operating temperature range is -40°C to 85°C. This component is commonly utilized in industrial automation, automotive, and consumer electronics applications.
Additional Information
Series: TX03RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 40MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 12K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | A/D 18x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 4V ~ 5.5V |
| Connectivity | I2C, SIO, UART/USART |
| Peripherals | DMA, LVD, WDT |
| Supplier Device Package | 100-LQFP (14x14) |
| Number of I/O | 83 |
| Programmable | Not Verified |
