TCD1304DG(8Z,K)
CCD LINEAR IMAGE SENSOR WDIP22Manufacturer: Toshiba Semiconductor and Storage
Categories: Image Sensors, Camera
Quality Control: Learn More
Toshiba Semiconductor and Storage TCD1304DG-8Z-K- is a CCD linear image sensor featuring an 8µm x 200µm pixel size and a 22-CERDIP package. This component operates with a supply voltage range of 3V to 5.5V and has an operating temperature range of -25°C to 60°C. The TCD1304DG-8Z-K- is suitable for applications in industrial automation, medical imaging, and scientific instrumentation where precise linear light detection is required. Its Wide DIP package facilitates integration into various system architectures.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Tray |
| Package / Case | 22-CDIP (0.400"", 10.16mm) |
| Type | CCD |
| Operating Temperature | -25°C ~ 60°C |
| Voltage - Supply | 3V ~ 5.5V |
| Pixel Size | 8µm x 200µm |
| Active Pixel Array | - |
| Supplier Device Package | 22-CERDIP |
