XBS506V1AR-G
DIODE SCHOTTKY 60V 5A SMBTManufacturer: Torex Semiconductor Ltd
Categories: Single Diodes
Quality Control: Learn More
Torex Semiconductor Ltd XBS506V1AR-G is a Schottky barrier rectifier designed for efficient power management. This diode features a 60V reverse voltage rating and a 5A forward current handling capability, suitable for applications requiring high current rectification. Its low forward voltage drop of 680mV at 5A minimizes power dissipation, contributing to overall system efficiency. The reverse leakage current is specified at 50 µA at 60V. The component is housed in a DO-221BA SMBT package with flat leads and an exposed pad, facilitating surface mounting. Operating at junction temperatures up to 150°C, the XBS506V1AR-G is engineered for reliability in demanding environments. This device finds application in power supplies, voltage clamping circuits, and reverse polarity protection across various industrial and automotive sectors. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-221BA, SMB Flat Leads Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 5A |
| Supplier Device Package | SMBT |
| Operating Temperature - Junction | 150°C |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Voltage - Forward (Vf) (Max) @ If | 680 mV @ 5 A |
| Current - Reverse Leakage @ Vr | 50 µA @ 60 V |
