XC9801B563KR-G
IC REG BOOST 5.6V 80MA 8MSOPManufacturer: Torex Semiconductor Ltd
Categories: DC DC Switching Regulators
Quality Control: Learn More
Boost Switching Regulator IC Positive Fixed 5.6V 1 Output 80mA 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width)
Additional Information
Series: XC9801RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up |
| Current - Output | 80mA |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Frequency - Switching | 300kHz |
| Voltage - Input (Max) | 5.5V |
| Topology | Boost |
| Supplier Device Package | 8-MSOP |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 1.8V |
| Voltage - Output (Min/Fixed) | 5.6V |
