XC74UL4066NR
IC SWITCH SPST-NOX1 20OHM SSOT25Manufacturer: Torex Semiconductor Ltd
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
The Torex Semiconductor Ltd XC74UL4066NR is a single-pole, single-throw (SPST) normally open analog switch featuring a low on-resistance of 20 Ohms maximum. This component offers a 1:1 multiplexer/demultiplexer circuit, suitable for signal routing applications. With a typical -3dB bandwidth of 200MHz, it supports efficient high-frequency signal transfer. The device operates with a single supply voltage ranging from 2V to 5.5V and is packaged in an SSOT-25 surface-mount configuration. Its operating temperature range is -40°C to 85°C. The XC74UL4066NR finds application in consumer electronics and industrial automation where reliable signal switching is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 20Ohm |
| -3db Bandwidth | 200MHz |
| Supplier Device Package | SSOT-25 |
| Voltage - Supply, Single (V+) | 2V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | - |
| Crosstalk | - |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | - |
| Switch Time (Ton, Toff) (Max) | 8ns, 20ns |
| Channel Capacitance (CS(off), CD(off)) | 0.5pF, 5pF |
| Current - Leakage (IS(off)) (Max) | - |
| Number of Circuits | 1 |
