IWSZPMW
INFRARED WALL SWITCH SENSORManufacturer: Thomas Research Products
Categories: Proximity/Occupancy Sensors Finished Units
Quality Control: Learn More
Thomas Research Products IWSZPMW is a passive infrared proximity/occupancy sensor designed for wall mounting. This unit provides up to 900 square feet of coverage and features a relay output for direct control of lighting loads. The IWSZPMW includes manual override functionality and operates within a 0°C to 50°C temperature range. Its white housing is suitable for standard wall installations. Applications include commercial and residential lighting control systems, where reliable occupancy detection is paramount. The sensor supports 120/277VAC supply voltages.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Color | White |
| Output Type | Relay |
| Mounting Type | Wall Mount |
| Operating Temperature | 0°C ~ 50°C |
| Voltage - Supply | 120/277VAC |
| Sensor Type | Passive Infrared |
| Coverage | 900 Square Feet |
| Manual Override | Yes |
