99188
LED ENG WARM WHT SQUARE 3000KManufacturer: Thomas Research Products
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Thomas Research Products LED Engine module, part number 99188, offers a warm white illumination at 3000K. This square-configured LED COB features a 11.00mm by 11.00mm footprint with a height of 1.80mm. It is designed for operation with a typical forward voltage of 12VAC and a maximum current of 400mA, with a test current of 300mA. At the test conditions, it achieves a luminous flux of 224 lumens (typical) and a luminous efficacy of 62 lm/W. The viewing angle is 120 degrees, and it utilizes a flat lens type. This component is suitable for various lighting applications within the architectural and general illumination sectors. Supplied in bulk packaging.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 11.00mm L x 11.00mm W |
| Type | LED Engine |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 12VAC |
| Height | 1.80mm |
| Current - Test | 300mA |
| Viewing Angle | 120° |
| Lens Type | Flat |
| Current - Max | 400mA |
| Lumens/Watt @ Current - Test | 62 lm/W |
| CCT (K) | 3000K |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 224lm (Typ) |
