0751-9002-99
INCLINOMETER ANALOG 90DEG 2AXSManufacturer: The Fredericks Company
Categories: Inclinometers
Quality Control: Learn More
The Fredericks Company 751 Series analog inclinometer, part number 0751-9002-99, is a two-axis sensor module designed for precise angle measurement up to ±90°. This component offers an 18Hz bandwidth, making it suitable for applications requiring moderate dynamic response. The inclinometer provides an analog output with sensitivities of 35mV/° for angle and 2V/g for acceleration. It operates within a voltage range of 7V to 35V. This device is commonly employed in industrial automation, construction equipment, and other platforms where accurate leveling and tilt sensing are critical. The module is supplied in boxed packaging.
Additional Information
Series: 751RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Module |
| Output Type | Analog |
| Sensitivity | 35mV/°, 2V/g |
| Interface | - |
| Axis | X, Y |
| Operating Temperature | - |
| Bandwidth | 18Hz |
| Measuring Range | ±90° |
| Voltage Rating | 7 V ~ 35 V |
Request a Quote
