0750-9002-99
INCLINOMETER RS-485 90DEG 2AXSManufacturer: The Fredericks Company
Categories: Inclinometers
Quality Control: Learn More
The Fredericks Company 750 Series 0750-9002-99 is a high-precision, dual-axis inclinometer module designed for demanding industrial and automation applications. This component offers a ±90° measuring range on both the X and Y axes, providing accurate tilt and angle measurements. Its RS-485 interface ensures robust communication in noisy environments, making it suitable for applications such as construction equipment, agricultural machinery, and robotics. The 18Hz bandwidth supports dynamic measurement needs. Operating within a wide temperature range of -40°C to 85°C and featuring a voltage rating from 7V to 35V, this module is built for reliability and performance in challenging conditions. The Fredericks Company's commitment to quality is evident in the 0.07°/LSB sensitivity, delivering precise data for critical control systems.
Additional Information
Series: 750RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Module |
| Output Type | RS-485 |
| Sensitivity | 0.07°/LSB |
| Interface | RS-485 |
| Axis | X, Y |
| Operating Temperature | -40°C ~ 85°C |
| Bandwidth | 18Hz |
| Measuring Range | ±90° |
| Voltage Rating | 7 V ~ 35 V |
