REF5025SHKQ
IC VREF SERIES 0.9% 8CFPManufacturer: Texas Instruments
Categories: Voltage Reference
Quality Control: Learn More
The Texas Instruments REF5025SHKQ is a high-precision, low-noise voltage reference IC offering a fixed 2.5V output with a ±0.9% tolerance. Designed for demanding applications, this device exhibits a low current consumption of 1.5mA and provides a stable output current of up to 7mA. Its superior temperature stability is characterized by a temperature coefficient of 40ppm/°C and a wide operating temperature range of -55°C to +210°C. The REF5025SHKQ features exceptionally low noise performance, with 7.5µVpp/V in the 0.1Hz to 10Hz bandwidth. Its input voltage range spans from 3.25V to 18V. This component is suitable for surface mount applications and is provided in an 8-CFP (Ceramic Flat Pack) package. Industries benefiting from this precision voltage reference include aerospace, defense, and high-performance test and measurement equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±0.9% |
| Packaging | Tube |
| Package / Case | 8-CSOIC (0.220"", 5.65mm Width) |
| Temperature Coefficient | 40ppm/°C |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Voltage - Input | 3.25V ~ 18V |
| Reference Type | Series |
| Operating Temperature | -55°C ~ 210°C (TA) |
| Current - Supply | 1.5mA |
| Supplier Device Package | 8-CFP |
| Voltage - Output (Min/Fixed) | 2.5V |
| Noise - 0.1Hz to 10Hz | 7.5µVpp/V |
| Noise - 10Hz to 10kHz | - |
| Current - Output | 7 mA |
