REF3330AIDCKTG4
IC VREF SERIES 0.15% SC70-3Manufacturer: Texas Instruments
Categories: Voltage Reference
Quality Control: Learn More
Texas Instruments REF3330AIDCKTG4 is a high-precision, low-power series voltage reference IC. This device provides a stable 3V output with a tight tolerance of ±0.15% and a low temperature coefficient of 30ppm/°C. Designed for surface-mount applications, it is supplied in an SC-70-3 package and available on tape and reel. The REF3330AIDCKTG4 exhibits a low output current capability of 5 mA and a quiescent current of just 8.5 µA, making it suitable for power-sensitive applications. Its input voltage range is 3.2V to 5.5V. This voltage reference is utilized in industries such as industrial automation, medical equipment, and portable electronics where accurate and stable voltage references are critical. The noise performance is rated at 84 µVp-p from 0.1Hz to 10Hz.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±0.15% |
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Temperature Coefficient | 30ppm/°C |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Voltage - Input | 3.2V ~ 5.5V |
| Reference Type | Series |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Current - Supply | 8.5µA |
| Supplier Device Package | SC-70-3 |
| Voltage - Output (Min/Fixed) | 3V |
| Noise - 0.1Hz to 10Hz | 84µVp-p |
| Noise - 10Hz to 10kHz | - |
| Current - Output | 5 mA |
