OPA693IDR
IC AMP BUFFER 8SOICManufacturer: Texas Instruments
Categories: Video Amps and Modules
Quality Control: Learn More
Texas Instruments OPA693IDR is a high-speed, low-power operational amplifier designed for demanding video buffer applications. This single-circuit device features an impressive 1.4 GHz -3dB bandwidth and a rapid 2500V/µs slew rate, enabling efficient signal amplification and conditioning. Operating from single or dual supply voltages ranging from 5V to 12V or ±2.5V to ±6V, the OPA693IDR offers a robust 120 mA output current capability. Its 8-SOIC (0.154", 3.90mm Width) package is suitable for surface mount assembly, commonly found in broadcast video, high-definition television (HDTV), and medical imaging systems. The device draws a low 13 mA quiescent current, contributing to power-efficient designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Applications | Buffer |
| Slew Rate | 2500V/µs |
| Voltage - Supply, Single/Dual (±) | 5V ~ 12V, ±2.5V ~ 6V |
| Supplier Device Package | 8-SOIC |
| Number of Circuits | 1 |
| Current - Supply | 13 mA |
| Current - Output / Channel | 120 mA |
| -3db Bandwidth | 1.4 GHz |
