LM6588MAX/NOPB
IC AMP TFT-LCD 14SOICManufacturer: Texas Instruments
Categories: Video Amps and Modules
Quality Control: Learn More
The Texas Instruments LM6588MAX-NOPB is a versatile 4-channel video amplifier from their VIP10™ series, designed for TFT-LCD panel applications. This component functions as both a gamma buffer and a VCOM driver, offering critical signal conditioning for display systems. It features a -3dB bandwidth of 24 MHz and a slew rate of 15V/µs, ensuring efficient signal transfer. The LM6588MAX-NOPB provides a rail-to-rail output and can deliver up to 230 mA of current per channel. Operating with a supply voltage range of 5V to 16V single or ±2.5V to ±8V dual, it exhibits a low supply current of 800 µA. Packaged in a 14-SOIC (0.154", 3.90mm width) surface-mount format, this device is supplied on tape and reel (TR). Its capabilities make it suitable for use in automotive, industrial, and consumer electronics sectors requiring high-quality display drivers.
Additional Information
Series: VIP10™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Applications | TFT-LCD Panels: Gamma Buffer, VCOM Driver |
| Slew Rate | 15V/µs |
| Voltage - Supply, Single/Dual (±) | 5V ~ 16V, ±2.5V ~ 8V |
| Supplier Device Package | 14-SOIC |
| Number of Circuits | 4 |
| Current - Supply | 800 µA |
| Current - Output / Channel | 230 mA |
| -3db Bandwidth | 24 MHz |
