LM2476TB/NOPB
IC AMP CRT DRVR TO247Manufacturer: Texas Instruments
Categories: Video Amps and Modules
Quality Control: Learn More
Texas Instruments LM2476TB-NOPB is a triple-channel CRT driver IC, ideal for high-resolution display applications. This component integrates three independent, high-speed amplifier channels within a single TO-247 package, facilitating compact and efficient system design. Key features include a bias clamp circuit for improved signal integrity and a wide supply voltage range of 60V to 85V. The LM2476TB-NOPB is designed with a typical supply current of 34 mA, making it suitable for power-sensitive systems. Its through-hole mounting type and TO-247-19 formed leads package ensure robust connectivity in demanding environments. This device finds application in display driver circuitry for cathode ray tube (CRT) monitors and televisions, where precise video signal amplification and management are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | TO-247-19 Formed Leads |
| Output Type | - |
| Mounting Type | Through Hole |
| Applications | Bias Clamp, CRT Driver |
| Slew Rate | - |
| Voltage - Supply, Single/Dual (±) | 60V ~ 85V |
| Supplier Device Package | TO-247 |
| Number of Circuits | 3 |
| Current - Supply | 34 mA |
