TL16C552APN
IC ASYNC COMM ELMNT DUAL 80-LQFPManufacturer: Texas Instruments
Categories: UARTs (Universal Asynchronous Receiver Transmitter)
Quality Control: Learn More
Texas Instruments TL16C552APN is a dual Universal Asynchronous Receiver/Transmitter (DUART) integrated circuit designed for high-performance serial communication. This component offers two independent, fully programmable UART channels, each capable of data rates up to 1Mbps. The TL16C552APN features 16-byte FIFOs for both transmit and receive operations, significantly reducing processor overhead. It supports modem control signals and includes false start bit detection for enhanced data integrity. The device is housed in an 80-LQFP package, suitable for surface mounting. Applications for this DUART include industrial automation, networking equipment, and embedded systems requiring robust serial interfaces.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Printer Port |
| Packaging | Bulk |
| Package / Case | 80-LQFP |
| Number of Channels | 2, DUART |
| Mounting Type | Surface Mount |
| Voltage - Supply | 4.75V ~ 5.25V |
| FIFO's | 16 Byte |
| Protocol | - |
| Data Rate (Max) | 1Mbps |
| Supplier Device Package | 80-LQFP (12x12) |
| With Auto Flow Control | - |
| With IrDA Encoder/Decoder | - |
| With False Start Bit Detection | Yes |
| With Modem Control | Yes |
