TSC2046EIZQCR
IC SCREEN CNTRL 12BIT 48BGAManufacturer: Texas Instruments
Categories: Touch Screen Controllers
Quality Control: Learn More
The Texas Instruments TSC2046EIZQCR is a 12-bit, 4-wire resistive touchscreen controller. This surface-mount component features an SPI interface for data communication and operates from a supply voltage range of 2.2V to 5.25V, with a typical current consumption of 780 µA. The device offers an internal voltage reference and is packaged in a 48-BGA MICROSTAR JUNIOR (4x4) form factor, supplied on tape and reel. Its 12-bit resolution ensures precise touch input accuracy. This controller is commonly utilized in industrial automation, automotive systems, and portable electronics where accurate resistive touchscreen interaction is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-VFBGA |
| Mounting Type | Surface Mount |
| Interface | SPI |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.2V ~ 5.25V |
| Resolution (Bits) | 12 b |
| Supplier Device Package | 48-BGA MICROSTAR JUNIOR (4x4) |
| Voltage Reference | Internal |
| Touchscreen | 4 Wire Resistive |
| Current - Supply | 780 µA |
