UC5601DWP
IC TERMINATOR SCSI 28SOICManufacturer: Texas Instruments
Categories: Signal Terminators
Quality Control: Learn More
Texas Instruments UC5601DWP, a SCSI terminator, offers 18 termination lines within a 28-SOIC surface-mount package. This component is designed for high-speed data transfer applications, specifically supporting SCSI standards requiring robust signal integrity. The UC5601DWP operates with a supply voltage range of 4V to 5.25V and features an operating temperature range of 0°C to 70°C. Its 28-SOIC package, measuring 7.50mm in width, facilitates efficient board space utilization. This device is commonly found in data storage systems, networking equipment, and industrial automation where reliable SCSI communication is essential.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Type | SCSI |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 4V ~ 5.25V |
| Number of Terminations | 18 |
| Supplier Device Package | 28-SOIC |
