SN65LVDS19DRFR
IC REDRIVER 1CH 2GBPS 8WSONManufacturer: Texas Instruments
Categories: Signal Buffers, Repeaters, Splitters
Quality Control: Learn More
Texas Instruments SN65LVDS19DRFR is a single-channel buffer/reDriveR designed for high-speed data transmission. This component supports a maximum data rate of 2Gbps and features PECL inputs that are translated to LVDS outputs, facilitating signal integrity over longer traces. The device operates within a supply voltage range of 2.375V to 3.6V and consumes a typical supply current of 30mA. With a small delay of 460ps, it is suitable for applications demanding precise timing. The SN65LVDS19DRFR is housed in an 8-WSON (2x2) package with an exposed pad for enhanced thermal performance, mounted via surface mount technology. This buffer is commonly utilized in networking equipment, industrial automation, and consumer electronics where reliable high-speed signal conditioning is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-WFDFN Exposed Pad |
| Delay Time | 460ps |
| Number of Channels | 1 |
| Mounting Type | Surface Mount |
| Output | LVDS |
| Type | Buffer, ReDriver |
| Input | PECL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.375V ~ 3.6V |
| Applications | - |
| Current - Supply | 30mA |
| Data Rate (Max) | 2Gbps |
| Supplier Device Package | 8-WSON (2x2) |
| Signal Conditioning | - |
