P82B96PW
IC REDRIVER I2C 1CH 8TSSOPManufacturer: Texas Instruments
Categories: Signal Buffers, Repeaters, Splitters
Quality Control: Learn More
Texas Instruments P82B96PW is a 2-channel I2C buffer/reDriver designed to extend I2C bus lengths and improve signal integrity. Operating at up to 400kHz, this device features low 4mA supply current and a wide 2V to 15V supply voltage range. The P82B96PW is packaged in an 8-TSSOP, suitable for surface mounting. With a typical input capacitance of 4pF, it effectively mitigates bus loading in applications requiring robust I2C communication. This component finds utility in industrial automation, consumer electronics, and automotive systems where reliable multi-device communication over extended distances is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-TSSOP (0.173"", 4.40mm Width) |
| Delay Time | - |
| Number of Channels | 2 |
| Mounting Type | Surface Mount |
| Output | 2-Wire Bus |
| Type | Buffer, ReDriver |
| Input | 2-Wire Bus |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2V ~ 15V |
| Applications | I2C |
| Current - Supply | 4mA |
| Data Rate (Max) | 400kHz |
| Supplier Device Package | 8-TSSOP |
| Signal Conditioning | - |
| Capacitance - Input | 4 pF |
Request a Quote
