DS15BR400TSQX/NOPB
IC REDRIVER LVDS 4CH 32WQFNManufacturer: Texas Instruments
Categories: Signal Buffers, Repeaters, Splitters
Quality Control: Learn More
The Texas Instruments DS15BR400TSQX-NOPB is a 4-channel LVDS Redriver designed for high-speed signal integrity applications. This electronic component offers data rates up to 2Gbps per channel, supporting CML, LVDS, and LVPECL inputs, with LVDS outputs. Its advanced signal conditioning includes output pre-emphasis, crucial for mitigating signal degradation in demanding environments. The DS15BR400TSQX-NOPB features a low supply current of 175mA and operates over a temperature range of -40°C to 85°C. Packaged in a 32-WQFN (5x5) with an exposed pad, it is suitable for surface mount applications. This device is commonly utilized in networking infrastructure, telecommunications equipment, and high-bandwidth data transmission systems where robust signal buffering and redriving are essential.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-WFQFN Exposed Pad |
| Delay Time | 1.0ns |
| Number of Channels | 4 |
| Mounting Type | Surface Mount |
| Output | LVDS |
| Type | Buffer, ReDriver |
| Input | CML, LVDS, LVPECL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 3.6V |
| Applications | LVDS |
| Current - Supply | 175mA |
| Data Rate (Max) | 2Gbps |
| Supplier Device Package | 32-WQFN (5x5) |
| Signal Conditioning | Output Pre-Emphasis |
| Capacitance - Input | 3 pF |
