XTR106UAG4
IC CURRENT TRANSMITTER 14SOICManufacturer: Texas Instruments
Categories: Sensor and Detector Interfaces
Quality Control: Learn More
Texas Instruments XTR106UAG4 is a high-precision current transmitter IC designed for industrial process control applications. This component facilitates the conversion of various input signals, including voltage, resistance (RTD), and thermistors, into a standard 4-20 mA current loop output. Featuring differential input capabilities, the XTR106UAG4 ensures robust signal acquisition in noisy environments. Its integrated 20 mA current source is programmable for sensor excitation. The device operates across a wide temperature range of -55°C to 125°C and is housed in a 14-SOIC package suitable for surface mounting. This IC is instrumental in applications such as process automation, sensor signal conditioning, and remote data acquisition systems across industries like manufacturing, energy, and environmental monitoring.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | Voltage |
| Mounting Type | Surface Mount |
| Type | Current Transmitter |
| Operating Temperature | -55°C ~ 125°C |
| Input Type | Differential |
| Supplier Device Package | 14-SOIC |
| Current - Supply | 20 mA |
| Programmable | Not Verified |
