UCC3806J
LOW POWER, DUAL OUTPUT, CURRENTManufacturer: Texas Instruments
Categories: Power Supply Controllers, Monitors
Quality Control: Learn More
Texas Instruments UCC3806J is a low-power, dual-output PWM controller designed for efficient power supply applications. This component features a current mode control architecture, facilitating precise regulation of complex power topologies. With an operating voltage range of 8V to 14.5V and a low supply current of approximately 1 mA, it is well-suited for power-sensitive designs. The UCC3806J is housed in a 16-CDIP package, with a through-hole mounting type, and operates within a temperature range of 0°C to 70°C. Its dual-output capability makes it advantageous for applications requiring multiple regulated voltage rails, commonly found in industrial automation, consumer electronics, and telecommunications equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-CDIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Voltage - Input | -0.3V ~ 14.8V |
| Operating Temperature | 0°C ~ 70°C (TJ) |
| Voltage - Supply | 8V ~ 14.5V |
| Applications | PWM Controller |
| Supplier Device Package | 16-CDIP |
| Current - Supply | 1 mA |
| Programmable | - |
