UC3844AD8TRG4
IC REG CTRLR PWM CM 8SOICManufacturer: Texas Instruments
Categories: Power Supply Controllers, Monitors
Quality Control: Learn More
Texas Instruments UC3844AD8TRG4 is a high-performance Pulse Width Modulation (PWM) controller designed for switch-mode power supplies. This voltage-mode controller features a fixed-frequency oscillator, error amplifier, current-sense comparator, and output driver. Operating from a 10V to 30V supply range, it draws a low 11mA quiescent current. The UC3844AD8TRG4 is packaged in an 8-SOIC (0.154", 3.90mm Width) surface-mount configuration, supplied on tape and reel. Its operating temperature range is 0°C to 70°C (TA). This component is widely utilized in power supply applications across industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Voltage - Input | -0.3V ~ 6.3V |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 10V ~ 30V |
| Applications | PWM Controller |
| Supplier Device Package | 8-SOIC |
| Current - Supply | 11 mA |
