UC2842AQD
IC CURR MODE PWM CNTRLLER 14SOICManufacturer: Texas Instruments
Categories: Power Supply Controllers, Monitors
Quality Control: Learn More
Texas Instruments UC2842AQD is a high-performance current-mode PWM controller. This 14-SOIC package device is designed for efficient power supply applications. It operates within a supply voltage range of 10V to 30V and features a low supply current of 11 mA. The UC2842AQD offers precise control over PWM operations, making it suitable for demanding power conversion designs. Its surface mount configuration and 14-SOIC package facilitate integration into compact board layouts. The operating temperature range of -40°C to 125°C ensures reliable performance across various environmental conditions. This component is widely utilized in industrial power supplies, automotive electronics, and advanced power management systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Voltage - Input | -0.3V ~ 6.3V |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Voltage - Supply | 10V ~ 30V |
| Applications | PWM Controller |
| Supplier Device Package | 14-SOIC |
| Current - Supply | 11 mA |
