TPS2032PG4
IC PWR SWITCH N-CHANNEL 1:1 8DIPManufacturer: Texas Instruments
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Texas Instruments TPS2032PG4 is a single-channel, high-side power distribution switch with integrated N-channel MOSFET technology. This device is designed for general-purpose switching applications, offering a robust solution for power management in various electronic systems. The TPS2032PG4 features a fixed current limit of 1A, coupled with over-temperature and undervoltage lockout (UVLO) fault protection, ensuring reliable operation under demanding conditions. Its output configuration is high-side, and it accepts a non-inverting input with ON/OFF control. The device includes a status flag for monitoring output conditions. With a low Rds(on) of 33mOhm (typical), it minimizes power dissipation. The TPS2032PG4 is housed in an 8-pin PDIP package and is rated for operation across a wide temperature range of -40°C to 125°C (TJ). This component is commonly utilized in industrial, consumer electronics, and telecommunications sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Output Type | N-Channel |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 33mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 1A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 8-PDIP |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
