LMD18200T
IC MTR DRV BIPLR 12-55V TO220-11Manufacturer: Texas Instruments
Categories: Motor Drivers, Controllers
Quality Control: Learn More
Texas Instruments LMD18200T is a fully integrated bipolar stepper motor driver featuring a Bi-CMOS and DMOS technology. This component provides a complete control and power stage for driving bipolar stepper motors. The LMD18200T offers a robust output current capability of 3A and operates across a wide voltage range of 12V to 55V for both supply and load. Its parallel interface simplifies integration into existing designs. The device is housed in a TO-220-11 package with formed leads, suitable for through-hole mounting. Operating within an extended temperature range of -40°C to 150°C (TJ), this motor driver is designed for general-purpose applications in various industrial sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-11 Formed Leads |
| Mounting Type | Through Hole |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 3A |
| Interface | Parallel |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side (2) |
| Voltage - Supply | 12V ~ 55V |
| Applications | General Purpose |
| Technology | Bi-CMOS, DMOS |
| Voltage - Load | 12V ~ 55V |
| Supplier Device Package | TO-220-11 |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | - |
