DRV8834PWP
IC MOTOR DRIVER BIPOLAR 24HTSSOPManufacturer: Texas Instruments
Categories: Motor Drivers, Controllers
Quality Control: Learn More
Texas Instruments DRV8834PWP is a bipolar stepper motor driver featuring integrated control and power stages. This fully integrated device utilizes Power MOSFET technology and supports step resolutions from full step to 1/32 microstepping. Designed for brushed DC and bipolar stepper motors, it offers a configurable output with four half-bridge drivers. The DRV8834PWP operates with a load and supply voltage range of 2.5V to 10.8V, delivering an output current of 1.5A. Its logic interface facilitates seamless integration into various control systems. The component is housed in a 24-HTSSOP package, suitable for surface mounting, and operates within an extended temperature range of -40°C to 150°C. This device finds application in general-purpose designs across multiple industries requiring precise motor control.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-PowerTSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1.5A |
| Interface | Logic |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 2.5V ~ 10.8V |
| Applications | General Purpose |
| Technology | Power MOSFET |
| Voltage - Load | 2.5V ~ 10.8V |
| Supplier Device Package | 24-HTSSOP |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | 1 ~ 1/32 |
