DRV8810PAP
IC MTR DRVR BIPOLAR 7-40V 64HQFPManufacturer: Texas Instruments
Categories: Motor Drivers, Controllers
Quality Control: Learn More
Texas Instruments DRV8810PAP is a bipolar stepper motor driver designed for applications requiring precise motor control. This device integrates a low-resistance, N-channel power MOSFET H-bridge output stage with a flexible SPI interface for control. It supports bipolar stepper motors with a wide operating voltage range of 7V to 40V, capable of delivering up to 800mA per phase. The DRV8810PAP offers adjustable current control through PWM, enabling microstepping from full step to 1/16th step resolution for smooth and accurate motor positioning. Its fully integrated solution includes protection features such as overcurrent, over-temperature, and under-voltage lockout. The 64-HTQFP (10x10) package is suitable for surface mounting and is utilized in general-purpose industrial automation and robotics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-PowerTQFP |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 800mA |
| Interface | SPI |
| Operating Temperature | 0°C ~ 120°C (TJ) |
| Output Configuration | Half Bridge (8) |
| Voltage - Supply | 7V ~ 40V |
| Applications | General Purpose |
| Technology | Power MOSFET |
| Voltage - Load | 18V ~ 40V |
| Supplier Device Package | 64-HTQFP (10x10) |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | 1 ~ 1/16 |
