TMS470R1A288PGEQ
IC MCU 16/32B 288KB FLSH 144LQFPManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments TMS470 series microcontroller, part number TMS470R1A288PGEQ. This 16/32-bit ARM7® core microcontroller operates at 48MHz and features 288KB of FLASH program memory with 16KB of RAM. It is housed in a 144-LQFP (20x20) surface mount package. Connectivity options include CANbus, C2Slb, I2C, SCI, and SPI. The device includes a 12-channel, 10-bit Analog-to-Digital converter, along with DMA, PWM, and WDT peripherals. Designed for demanding applications with a supply voltage range of 1.71V to 2.05V and an operating temperature of -40°C to 125°C, this component is suitable for automotive, industrial automation, and aerospace sectors.
Additional Information
Series: TMS470RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 48MHz |
| Program Memory Size | 288KB (288K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM7® |
| Data Converters | A/D 12x10b |
| Core Size | 16/32-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 2.05V |
| Connectivity | CANbus, C2Slb, I2C, SCI, SPI |
| Peripherals | DMA, PWM, WDT |
| Supplier Device Package | 144-LQFP (20x20) |
| Number of I/O | 93 |
| Programmable | Not Verified |
