TMS320F2806GGMS
IC MCU 32BIT 64KB FLASH 100BGAManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments TMS320F2806GGMS is a 32-bit C2000™ C28x Fixed-Point microcontroller featuring a 100MHz C28x core. This device offers 64KB of FLASH program memory and 10KB of internal RAM, configured as 32K x 16. It includes multiple communication interfaces such as CANbus, I2C, SCI, SPI, and UART/USART. The TMS320F2806GGMS is equipped with a 16-channel, 12-bit Analog-to-Digital converter and essential peripherals including Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Designed for surface mount applications, it is housed in a 100-BGA MICROSTAR (10x10) package. Operating within a temperature range of -40°C to 125°C (TA) and requiring a supply voltage between 1.71V and 1.89V, this microcontroller is suitable for demanding applications in the industrial and automotive sectors.
Additional Information
Series: C2000™ C28x Fixed-PointRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 100-LFBGA |
| Mounting Type | Surface Mount |
| Speed | 100MHz |
| Program Memory Size | 64KB (32K x 16) |
| RAM Size | 10K x 16 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | C28x |
| Data Converters | A/D 16x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 1.89V |
| Connectivity | CANbus, I2C, SCI, SPI, UART/USART |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 100-BGA MICROSTAR (10x10) |
| Number of I/O | 35 |
| Programmable | Not Verified |
