TMS320F28023DAT
IC MCU 32BIT 64KB FLASH 38TSSOPManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments TMS320F28023DAT is a 32-bit C28x C2000™ C28x Piccolo™ microcontroller. This single-core device operates at 50MHz and features 64KB of FLASH program memory (32K x 16) and 6KB of RAM. On-chip peripherals include a Brown-out Detect/Reset, POR, PWM, and WDT. It offers seven 12-bit Analog-to-Digital converters for data acquisition. Connectivity options include I2C, SCI, SPI, and UART/USART interfaces. The device is housed in a 38-TSSOP (0.240" width) surface-mount package. Operating voltage ranges from 1.71V to 1.995V, with an operating temperature range of -40°C to 105°C. This component is suitable for applications in industrial automation, motor control, and power systems.
Additional Information
Series: C2000™ C28x Piccolo™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 38-TSSOP (0.240"", 6.10mm Width) |
| Mounting Type | Surface Mount |
| Speed | 50MHz |
| Program Memory Size | 64KB (32K x 16) |
| RAM Size | 6K x 16 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | C28x |
| Data Converters | A/D 7x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 1.995V |
| Connectivity | I2C, SCI, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Supplier Device Package | 38-TSSOP |
| Number of I/O | 20 |
| Programmable | Not Verified |
