S5LS10116ASPGEQQ1
IC MCU 16/32BIT 1MB FLSH 144LQFPManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments Hercules™ TMS570 ARM® Cortex®-R microcontroller, part number S5LS10116ASPGEQQ1, features an ARM® Cortex®-R4F core capable of 16/32-bit processing at 140MHz. This component offers 1MB of FLASH program memory and 128KB of RAM. Integrated peripherals include DMA and POR. Connectivity options comprise CANbus, LINbus, SCI, SPI, and UART/USART. The device is equipped with a 20x12-bit Analog-to-Digital converter. Designed for automotive applications, it meets AEC-Q100 qualification and operates within a temperature range of -40°C to 125°C. The S5LS10116ASPGEQQ1 is available in a 144-LQFP surface mount package and requires a supply voltage between 1.35V and 1.65V.
Additional Information
Series: Hercules™ TMS570 ARM® Cortex®-RRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 140MHz |
| Program Memory Size | 1MB (1M x 8) |
| RAM Size | 128K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-R4F |
| Data Converters | A/D 20x12b |
| Core Size | 16/32-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.35V ~ 1.65V |
| Connectivity | CANbus, LINbus, SCI, SPI, UART/USART |
| Peripherals | DMA, POR |
| Supplier Device Package | 144-LQFP (20x20) |
| Grade | Automotive |
| Number of I/O | 68 |
| Programmable | Not Verified |
| Qualification | AEC-Q100 |
