MSP430P315SIDL
IC MCU 16BIT 16KB OTP 48SSOPManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments MSP430P315SIDL, a 16-bit microcontroller from the MSP430x3xx series, features an MSP430 CPU16 core operating at 8MHz. This OTP (One-Time Programmable) device offers 16KB of program memory and 512 bytes of RAM, suitable for applications requiring efficient code execution and data handling. Connectivity is provided via UART/USART interfaces, and it includes peripherals such as LCD drivers, Power-On Reset (POR), and a Watchdog Timer (WDT). The integrated Slope Analog-to-Digital converter facilitates analog signal conversion. Housed in a 48-SSOP package, it supports surface mount assembly and operates within a temperature range of -40°C to 85°C. Typical applications include industrial control, consumer electronics, and portable devices.
Additional Information
Series: MSP430x3xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 48-BSSOP (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Speed | 8MHz |
| Program Memory Size | 16KB (16K x 8) |
| RAM Size | 512 x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | OTP |
| EEPROM Size | - |
| Core Processor | MSP430 CPU16 |
| Data Converters | Slope A/D |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | UART/USART |
| Peripherals | LCD, POR, WDT |
| Supplier Device Package | 48-SSOP |
| Number of I/O | 14 |
| Programmable | Verified |
