MSP430F5636IZQWT
IC MCU 16BIT 128KB FLASH 113BGAManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments MSP430F5xx series microcontroller, part number MSP430F5636IZQWT, features a 16-bit MSP430 CPUXV2 core operating at up to 20MHz. This device offers 128KB of FLASH program memory and 18KB of RAM. Connectivity options include I2C, IrDA, LINbus, SCI, SPI, UART/USART, and USB. Integrated peripherals include Brown-out Detect/Reset, DMA, POR, PWM, and WDT. The device also includes 16-channel 12-bit Analog-to-Digital converters and 2-channel 12-bit Digital-to-Analog converters. Supplied in a 113-BGA Microstar Junior (7x7) package for surface mounting, it operates within a voltage range of 1.8V to 3.6V and an ambient temperature range of -40°C to 85°C. This microcontroller is suitable for applications in industrial automation, consumer electronics, and automotive systems.
Additional Information
Series: MSP430F5xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 113-VFBGA |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 18K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | MSP430 CPUXV2 |
| Data Converters | A/D 16x12b; D/A 2x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Connectivity | I2C, IrDA, LINbus, SCI, SPI, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Supplier Device Package | 113-BGA Microstar Junior (7x7) |
| Number of I/O | 74 |
| Programmable | Not Verified |
